Advanced Lighting for HD/DV Camcorders

Frezzi is the world leader for on-camera lighting used by
virtually all network news operations, cable, and sports
channels for over 70 years. Frezzi continues to expand its
family of award winning quartz and HMI lighting tailored to
today’s smaller Mini-HD and DV camcorders.
T
he Micro-Fill series provides tungsten or daylight balanced
light. The Standard and Dimmer Micro-Fill are balanced at
3200K and provide 5600K with the optional Combo Accessory
MRDF. The Dimmer Micro-Fill offers an advanced dimmer
circuit for controlling light output providing optimal DV
performance without radio interference.
Frezzi’s new line of Micro-Fills and Micro-Sun Guns are
affordably priced and designed with the same professional
features as their big brother counterparts, the award winning
Frezzi Mini-Fills and HMI Mini-Sun Guns. Improve your image
quality, put a Frezzi on your camera and see the results.




Features & Benefits

• Compact, lightweight, ruggedized camera top lighting
• Universal shoe mount, 1/4-20 thread, 1/2” stud mount
included
• Quality construction with professional features
• Available with all commonly requested connectors
• 3 models: on/off, dimmer, HMI daylight (5600K)
• Many accessories & options. Full kits available with
batteries



Choice of Connectors





Frezzi Micro-Fill Series Product Guide

Standard Micro-Fill
on/off quartz

Dimmer Micro-Fill Dimmable quartz

Micro-Sun Gun HMI
on/off HMI

DC Connector

Item No. Model No. Item No. Model No. Item No. Model No.

Connector Description

91301 MRF-NP1 91401 MRFIC-NP1 92801 MRA-NP1

NP-1 battery connector, 4’ cable

91302 MRF-NP1S 91402 MRFIC-NP1S 92802 MRA-NP1S

NP-1 battery connector, 2’ cable

91306 MRF-PT 91406 MRFIC-PT 92803 MRA-PT

Power-tap connector, 2’ cable

91303 MRF-PTS 91403 MRFIC-PTS 92804 MRA-PTS

Power-tap connector, 1’ cable

91304 MRF-4X 91404 MRFIC-4X 92805 MRA-4X

XLR-4 male connector, 4’ cable

91305 MRF-5X 91405 MRFIC-5X 92806 MRA-5X

XLR-5 male connector, 4’ cable

91307 MRF-12P 91407 MRFIC-12P 92807 MRA-12P

Cigarette plug, 4’ cable

91308 MRF-12C 91408 MRFIC-12C 92808 MRA-12C

BP-90 socket, 4’ cable

91309 MRF-12S 91409 MRFIC-12S 92809 MRA-12S

BP-90 plug, 2’ cable

All models operate on 12-14.4 Volts

Lamps

Item No. Model No. Watts Volts Kelvin Life (hrs) fc@5' Beam Sp. Bulb Type
97011 FTH 35 12-14 3200K 2000 103 30deg flood Tung.
97012 FTD 20 12-14 3200K 2000 52 30deg flood Tung.
97105 FAB-10 10 12-14 5600K 1000 40 25deg flood HMI
97108 LED-2 2 12-14 5600K 1000 40 25deg flood HMI

Lamps measured with clear glass except FAB-10All Lamps supplied with diffused glass for soft professional output.
Recommended with Micro-Fill clear glass assembly P/N 3371C. Specification subject to change without notice.
